Akash

- Smart Solar Street Light

Aakash is a family of smart outdoor lighting solutions. It boasts of smart, patent pending, energy based dimming algorithm, which ensures batteryโ€™s depth of discharge within safe limits to maximizing battery life and delivering light output for the intended duration. It implements MPPT charge controller to extract maximum power from solar panel as well as constant current LED driver. It implements features like dimming and multiple sensor interfaces etc., for remote and optimized usage.

Amogh Solar Street Light

Highlights

  • Automatic Dusk to Dawn operation
  • Time based dimming up to 6 segments
  • Patent pending energy dimming
  • MPPT Solar charge controller (Extracts up to 30% more)
  • Multi chemistry 4 stage battery charging algorithm
  • High efficiency dimmable boost LED light driver
Indicators
  • Charging active
  • Battery Lowย
  • Empty
Protection
  • Battery Low Cut off
  • LED Open Fault โ€“ Auto recovery
  • Battery reverse protection
Options
  • Sensor integration,
    – Motion detection
    – Temperature & Humidity
  • Radios
    – GSM / WiFi / BLE / NBIoT
    – <1GHz
  • TruHybrid
    – Grid + Solar
Communication
  • Command brightness level remotely
  • Parameters available from the Luminary
    – Status -> Charging | Light ON | Faults
    – Battery voltage
    – Charging current
    – Panel voltageLED string voltage
    – Power โ€“ Charging and Discharging
    – Energy โ€“ Charge and Discharge
